(AT 45 KM/H WITH 75 KG DRIVER)
Seat Height: 780mm
DRIVING EXPERIENCE AT UP TO 95 KM/H
The EK3 is fast on the road and achieves a top speed of 95 km/h. The 14-inch front wheel and 13-inch rear wheel offer excellent manoeuvrability. Safety is provided by the efficient CBS braking system.
HIGHLY EFFICIENT ECONOMICAL MOTOR
The Center Motor developed by HORWIN creates an output of 6.2 kW at a speed of 95km/h. The EK3 accelerates to 60 km/h in six seconds,with full torque being activated immediately when the throttle is activated. The constant power of the engine motor ensures smoother running under all road conditions.
BATTERY WITH ITS OWN MANAGEMENT
The EK3 scooter can be equipped with two lithium-ion batteries that are easily removable. Both batteries can be charged simultaneously. The battery is supplied 18650 lithium-ion battery cells. The SOC monitoring system and the modern battery management system can prevent malfunctions. Among other things, they provide protection against over-charging, discharging, over-voltage, short circuit and monitor the temperature of the batteries. One battery cell has a capacity of 10.44Wh, the whole battery has 2.88kWh. The battery life is over 1000 cycles. The standard charging current is 10A. The charging time of one battery is 4 hours. An intelligent charger is used for this.
LED DAYTIME RUNNING LIGHT FOR MORE SAFETY
The automatic daytime running light DRL (Daytime Running Light) shines with an intensive white xenon lamp. This improved lighting brings more safety- especially on rainy and foggy days. An automatic light switch-off delay lights your way to the garage or entrance door when you leave the vehicle.
LED HEAD LIGHTS WITH THREE LENSES
The head lights are equipped with LED lamps. With their brighter and whiter light they literally cut through the night and are far superior to standard incandescent lamps. Compared to the yellow light of conventional halogen lamps, LED lamps also come very close to the colour of daylight. They give the driver a more natural impression of the road situation.
SMART PHONE CAN BE CHARGED WHILE DRIVING
While you are cruising with your EK3, you can charge your smart phone on board via the USB connector. This convenient additional function offers you the security of always having the
battery of your mobile companion sufficiently full- no matter when and where.
REMOTE CONTROL VEHICLE KEY
Conveniently, the vehicle key has a remote control built in: This way you can start, stop and even lock the scooter.
And all this without having to put the key in the ignition lock!
CBS BRAKING SYSTEM
The CBS braking system will split braking force between the front and rear brake discs when you brake in an emergency, reducing stopping distance and ensuring a safe brake at high speeds.
LOW MAINTENANCE BRAKE SYSTEM
FULL CONTROL WITH A MODERN COCKPIT
LIGHT WEIGHT WHEEL
HUBS PROVIDE STRENGTH!
